| Parameter Name | Parameter Units | Parameters |
| weight | kg | 26 |
| length | mm | 659 |
| cylinder dia. | mm | 80 |
| piston stroke | mm | 60 |
| air consumption | m³/min | ≤3.4 |
| impact frequency | Hz | ≥35 |
| impact strength | J | ≥63 |
| drilling speed | mm/min | ≥400 |
| drilling dia. | mm | Φ34~45 |
| drilling depth | m | 5 |
| shank | mm | 22×108±1 (hex X length) |
